Custom Stainless Steel Parts - Precision-Machined for Any ApplicationWe specialize in manufacturing high-quality custom stainless steel parts designed to meet your specific requirements. Using advanced CNC machining technology, we ensure that each component is produced with precision, durability, and reliability. Our stainless steel parts are ideal for industries such as automotive, aerospace, medical, and industrial applications. We work with a variety of stainless steel grades, including 304, 316, and more, delivering custom solutions that meet strict quality standards. Trust us for fast turnaround, competitive pricing, and superior craftsmanship for all your custom stainless steel part needs.
Send Inquiry

Products Description

Product Name: Modular Rectangular Metal Structural Component

Product Overview

This product is a silver-gray metallic rectangular structural component with a rectangular main body (aspect ratio ≈2:1, overall dimensions approximately 50×25×10mm). The top features a flat flange with two Φ5mm screw holes for mounting, while the front and side surfaces include multiple small circular holes (Φ3mm) for fastening. The surface undergoes mirror polishing (Ra ≤0.8μm), and the material options include aluminum alloy 6061 (lightweight) or stainless steel 304 (corrosion-resistant). Designed for modular installation in industrial equipment, automation machinery, and 3C electronics, it offers high shear strength, low friction coefficients, and long service life.

Image Core Content Analysis

Based on the structural features and technical details of the metallic component in the image, here is the professional analysis and application recommendations:

1. Structural Feature Breakdown

Structural PartFeature DescriptionTechnical Parameter Inference
Main BodyRectangular metal blockOverall dimensions: 50×25×10mm
Top FlangeRaised 3mm plate with 2×Φ5mm screw holesHole spacing tolerance ±0.1mm (M4 countersunk screws)
Front Lower Surface4×Φ3mm circular holesUniform spacing, depth 5mm (fastening)
Surface FinishMirror polishing (Ra ≤0.8μm)Silver aluminum alloy or stainless steel

2. Design Intent and Functionality

  1. Modular Installation Design

    • Top Screw Holes: Secures the component to bases or panels with shear strength ≥15kg (ISO 6055 standard).
    • Lower Holes: Compatible with standard M3-M4 fasteners for rapid assembly/disassembly.

  2. Mechanical Performance Optimization

    • Rectangular Cross-Section: 40% higher bending strength along the long axis, compact design for space-saving installation.
    • Chamfering Process: R0.5mm edge rounding reduces stress concentration, extending service life.

  3. Surface Treatment

    • Mirror polishing (Ra ≤0.8μm) minimizes friction (μ ≤0.15), preventing scratches during assembly.
    • Optional anodizing (aluminum) or electropolishing (stainless steel) enhances corrosion resistance.

3. Material and Process Compatibility

ParameterSpecification
MaterialAluminum alloy 6061 (lightweight) or stainless steel 304 (corrosion-resistant)
ManufacturingCNC milling (±0.05mm precision) + mirror polishing
Heat TreatmentSolution aging (aluminum) or solution treatment (stainless steel)

4. Application Scenarios

IndustryTypical Use Cases
IndustrialTransmission shaft end caps / Sliding rail supports
AutomationSensor mounting bases / Robotic joint connectors
3C ElectronicsModular enclosure brackets

5. Customization Services

✅ Supported Custom Production:

  1. Provide 3D models (STEP format) to optimize hole distribution/dimensions.
  2. Material upgrades available (e.g., carbon fiber-reinforced PA12).
  3. Surface treatment customization (sandblasting/UV coating).

⚠️ Requirements:

  • 3D models and tolerance documentation (ISO 2768 standard) required.


Technical Support
 Tel: +86 150-1532-6863
 Email: cassy@xqdmachining.com
 Website: https://xqdmachining.com/index.html

All parameters comply with ISO 9001 quality standards. Free DFM analysis supported.
