Plastic parts

CNC Plastic Parts - Precision Machining for Custom Plastic ComponentsOur CNC plastic parts manufacturing service delivers high-precision, custom plastic components tailored to your specifications. Using advanced CNC machining technology, we craft durable parts from a variety of materials like ABS, polycarbonate, nylon, and PEEK. Whether for prototypes or large-scale production, our expertise ensures your parts meet the highest standards for quality, accuracy, and performance. Ideal for industries like automotive, medical, electronics, and consumer goods, trust us for fast, reliable, and cost-effective CNC plastic parts.
Send Inquiry

Products Description

Product Name: Industrial-Grade White Plastic Component with Structural Reinforcement

Product Overview

This product is a white PA66 engineering plastic component featuring a cylindrical body with a flared circular base. The surface is smooth and glossy, with concentric rings on the body for structural reinforcement and improved grip. The base includes evenly spaced circular indentations and symmetrical small holes for secure fastening. Designed for industrial or household applications, it is suitable for use as a nozzle, plug, or connector.

Core Parameters

ParameterTechnical Specifications
MaterialPolyamide 66 (PA66)
DimensionsΦ25mm × 50mm (Diameter × Height)
Base ShapeFlared circular base with Φ40mm outer diameter
Surface FinishSmooth (Ra ≤0.8μm)
Reinforcement4 concentric annular ribs (height 1mm)
Hole Specifications4×Φ3mm symmetrical holes (±0.1mm tolerance)
Load CapacityStatic load ≥15kg (ISO 6055 standard)

Design Features

Structural Reinforcement

  • Concentric annular ribs enhance axial strength by 40%.
  • Flared base improves stability during installation.

Ergonomic Design

  • Tapered body design ensures precise alignment during assembly.
  • Circular indentations on the base prevent rotational slippage.

Surface Treatment

  • Polished surface (Ra ≤0.8μm) reduces friction during handling.
  • Optional UV coating (wear resistance increased by 2x).

Manufacturing Process

Process StepTechnical Details
Injection Molding- Material: PA66 (glass fiber reinforced optional)
- Mold temperature: 80℃-120℃
- Cooling time: 15-20 seconds
Post-Processing- Annealing at 120℃ for 2 hours (stress relief)
- CNC polishing (Ra ≤0.8μm)

Application Scenarios

IndustryTypical Use Cases
IndustrialHydraulic nozzle/valve connector
AutomotiveSensor housing/coolant pipe fitting
HouseholdPlumbing fittings/appliance components

Customization Service

✅ Support Custom Production:

  1. Provide 3D models (STEP format) for design optimization.
  2. Adjustable features:
    • Hole patterns (M3-M6 threaded options).
    • Material upgrades (e.g., carbon fiber reinforced PA12).
  3. MOQ: 50 pieces (mixed configurations allowed).

⚠️ Requirements:

  • 3D model and tolerance documentation required.
  • Complex structures may incur mold development fees (¥2,000-5,000).

Technical Support

 Tel: +86 150-1532-6863
 Email: cassy@xqdmachining.com
 Website: https://xqdmachining.com/index.html

All parameters comply with ISO 9001 quality standards.
